Performance:
- Scan volume: Up to 20.3 (diameter) x 20.3 cm (H), [8 x 8 in.]
- Dimensional accuracy: ± 2.0 mm [± 0.079 in]
- Detail resolution: 0.5 mm [0.0197 in]
- Triangles per 3D model: Approx. 200K
- Scan speed: Approx. 12 minutes
- Steps per rotation: 800 per rotation
- Optimal Light Conditions: Artificial indoor light
- Maximum weight on turntable: 3 kg [6.6 lbs]
Software:
- Included Software: MakerWare for Digitizer
- Exported File Types: STL, Thing
- Operating Systems: Windows (7+), Mac OSX (10.7+), Linux (Ubuntu 12.04+)
Components:
- Lasers: Two eye-safe Class 1 laser line generators
- Camera: 1.3 megapixel CMOS image sensor
- Enclosure Material: PC ABS
- Connectivity: USB connection
- Stepper Motor: 0.9° step angle with 1/16 micro-stepping
- Dimensions:
- Product Dimensions: 47.5 (L) x 20.3 (H) x 41.1 cm (W), [18.7 x 8.0 x 16.2 in]
- Product Weight: 2.1 kg [4.7 lbs]
